DescriptionASR1013 SpecificationPhysical specificationsNote: Depth applies to chassis edge-to-edge dimension and does not include protrusions such as card handles, power-supply handles, and cable management brackets.Refer to the applicable hardware installation guide for additional details.Height: 22.8 in. (579.1 mm)Width: 17.2 in. (437.4 mm)Depth: 18.15 in. (461.0 mm)Weight:● 184.0 lb (83.46 kg) (with redundant AC power supply, SPA, route processor, SIP blank covers, two Cisco ASR 1000 Series 40-Gbps ESPs [ASR1000-ESP40] or ASR1000 Series 100-Gbps ESPs [ASR1000-ESP100] or ASR1000 Series 200-Gbps ESPs [ASR1000-ESP200], two Cisco ASR 1000 Series RP2s [ASR1000-RP2], six Cisco ASR 1000 Series 40-Gbps SIPs [ASR1000-SIP40], and no SPAs)Default memory8-GB DRAM RP28-GB DRAM RP3Number of SIPs or Ethernet line cards supported6Shared port adapters24 SPA slotsEthernet port adapters12 EPA slotsCisco ASR 1000 Series ESP2 ESP slotsRoute processor2 route-processor slotsRedundancyHardware: YesBuilt-in Gigabit Ethernet ports0Built-in 10 Gigabit Ethernet portNoNetwork interface moduleNoCisco ASR 1000 SeriesCisco ASR 1013ESP supportCisco ASR 1000 Series 40-Gbps ESP (ASR1000-ESP40), Cisco ASR 1000 Series 100-Gbps ESP (ASR1000-ESP100), and Cisco ASR 1000 Series 200-Gbps ESP (ASR1000-ESP200)ESP bandwidth40 to 200 GbpsESP memoryCisco ASR 1000 Series 40-Gbps ESP (ASR1000-ESP40): 8-GB DRAMCisco ASR 1000 Series 100-Gbps ESP (ASR1000-ESP100): 16-GB DRAMCisco ASR 1000 Series 200-Gbps ESP (ASR1000-ESP200): 32-GB DRAMSIPs and Ethernet line cardsSupports Cisco ASR 1000 Series 40-Gbps SIP Carrier Card (ASR1000-SIP40), Cisco ASR1000 Series MIP 100-Gbps Carrier Card (ASR1000-MIP100), and ASR 1000 Fixed Ethernet Line Card; two 10 GE twenty 1 GE (ASR1000-2T 20X1GE) line cards; and six 10 GE line cards (ASR1000-6TGE)Embedded hardware-based encryptionYes: On Cisco ASR 1000 Series 40-Gbps ESP (ASR1000-ESP40) with up to 11-Gbps crypto support throughput, Cisco ASR 1000 Series 100-Gbps ESP (ASR1000-ESP100) with up to 29-Gbps crypto support throughput, and Cisco ASR 1000 Series 200-Gbps ESP (ASR1000-ESP200) with up to 78-Gbps crypto support throughputMinimum Cisco IOS XE Software releaseCisco ASR 1000 Series 40-Gbps ESP (ASR1000-ESP40) requires Cisco IOS XE Software Release 3.1.0S, ASR 1000 Series 100-Gbps ESP (ASR1000-ESP100) requires Cisco IOS XE Software Release 3.7.0S, and ASR 1000 Series 200-Gbps ESP (ASR1000-ESP200) requires Cisco IOS XE Software Release 3.10.0SRack-mountingYes: 19-inchWall-mountingNoExternal USB flash memory1-GB USB flash-memory supportRedundant power supplyYes: Quad power supplies (redundant pairs) by default; option of either AC or DC power suppliesNote: A mix of AC and DC power supplies is not supported.Power inputWorldwide ranging AC (180 to 264V; 240V; 60 or 50 Hz nominal)Worldwide ranging DC(-40.5 to -72; -48V nominal)Power consumption● Maximum (DC): 4200W● Maximum (AC-high line): 4000W● Maximum (out): 3390WAirflowFront-to-backOperating temperature (nominal)Same as for Cisco ASR 1001-XOperating temperature (short-term)Same as for Cisco ASR 1001-XOperating humidity (nominal) (relative humidity)Same as for Cisco ASR 1001-XOperating humidity (short-term)Same as for Cisco ASR 1002Storage temperatureSame as for Cisco ASR 1001-XStorage humidity (relative humidity)Same as for Cisco ASR 1001-XOperating altitudeSame as for Cisco ASR 1001-XNetwork Equipment Building Standards (NEBS)GR-1089 and GR-63EMC standardsSame as for Cisco ASR 1001-XSafety Standard
