DescriptionASR1000-ESP40 SpecificationPerformanceUp to 25 MppsVariable forwarding performance, depending on features configuredBandwidthUp to 40 GbpsFor the combination of commonly used features Firewall or NATShared by all Cisco ASR 1000 SIP (ASR1000-SIP10 or ASR1000-SIP40) cardsUp to 12.9 GbpsFor plain IPsec encryption (1400-byte packets)ScalingAccess controlUp to 4,000 unique ACLs and 100,000 ACEs per systemBroadbandUp to 64,000 sessions and 16,000 L2TP tunnelsIPUp to:● 4,000,000 IPv4 or 4,000,000 IPv6 routesMulticast: 100,000 routes and 4,000 groupsQoSFlexible number of queues per system:● Up to 128,000 queues● Three levels of hierarchy● Two LLQ queues per policy, with up to 4,000 policies8-kbps policing and queuing granularity<100-microsecond latency for high-priority applicationsReal-time trafficUp to 4,000 CRTP sessionsSecurityUp to:● IPsec: 8,000 tunnels● Firewall or NAT: 2,000,000 sessions and 200,000 sessions-per-sec setup rate● Carrier-Grade NAT: 4,000,000 sessionsL3VPNUp to 8,000 VRF instancesGREUp to 4,000 tunnelsCisco Unified Border Element (SP Edition)Up to 64,000 sessions (each session represents a complete voice call with 14 SIP messages per call; that is, two call legs on the SBC consisting of two media legs for a bidirectional media flow and seven SIP messages per call leg)
